EZprofile® Toolset

Quite less hassle for profiling your lenses thanks to our comprehensive workflow!

Starting at 1 399€/seat

EZprofile®, our innovative software solution, is aimed at virtual studio operators for the calibration of their optical lenses, regardless of their type; Cine Prime or Broadcast zoom lens.

Released as a stand-alone toolset, the solution implements a straightforward process with complete control of the data at every step, to deliver an accurate calibrated lens profile, in a limited time.

AUTOMATED FREED OR MANUAL LENS DATA INPUT

PATTERN-BASED INPUT WITH CHECKERBOARD FILES INCLUDED

SMART INTERPOLATION OF CAPTURED DATA

MULTI-3D ENGINES EXPORT PROCESS

ALL ZOOM & FOCUS VALUES INCREMENTATION

COMPREHENSIVE CALIBRATION PROCESS ACCROSS 4 STEPS

PREMIUM SET OF FEATURES EMBEDDED

ACHIEVE A COMPLETE CONTROL OF YOUR LENS DATA AT EVERY STEP

Recommended Software & Hardware configuration

To operate EZprofile® on your PC or laptop, use of one SDI to USB converter such as the AJA U-TAP 3G-SDI USB 3.0 capture device

Alternatively, user can also use one Black Magic Decklink video acquisition card combined with a webcam emulator such as OBS Studio

OS: Windows 64 bits

CPU: Intel or AMD multicore with at least 4 cores

RAM: at least 8 Gigs DDR4

STEP 1 :

LENS DATA CAPTURE

Directly processed within the interface, start capturing data using inputs from a pre-recorded images directory implementing checkerboards-based patterns: the checkerboard files are already included into the tool!

As complement to the capture of the patterns, EZprofile® will also take advantage of the live tracking input over the FreeD protocol, at time of capturing every lens data.

Profile your lens in 4 steps!

STEP 2 :

DATA PROCESSING

Create an exhaustive lens profile for the whole range of zoom and focus values of your specific lens.

EZprofile® will allow you to process data to get lens parameters at specific key frame, along with zoom and focus values!

Depending on the complexity of your lens, the whole process will take you from 1 to 3 hours to finalize your lens calibration from the beginning.

back

STEP 3 :

PARAMETERS OVERVIEW

Visualize each lens parameter as smooth 3D surface: simply check it and edit it if necessary!

EZprofile® will generate very accurate lens data thanks to a unique mathematical extrapolation
between the various measure points.

User will get access to an exhaustive lens curve
from any type of camera, whether Cine-type Prime lenses or encoded/motorized zoom lenses!

back

Profile your lens in 4 steps!

Profile your lens in 4 steps!

STEP 4 :

LENS PROFILE EXPORT

You are now ready to export your generated lens profile to your favorite render engine!

EZprofile® can generate any lens profile in various formats, compatible with the 3D render engine you are working with. At launch, the solution will provide compatibility with Unreal Engine 4, Zero Density, Pixotope and Aximmetry.

At later stage in 2022, we are also planning to add dedicated support of Disguise, Vizrt, Ventuz and Unity pipelines among others.

back

Step 1

Step 2

Step 3

Step 4

scroll

Order your license of EZprofile®

Studio License for internal use only (Perpetual seat license).
License for service provider or partner available on quote.
Software available in downloadable redistribution only.
License does not include upgrades nor support plans.

Starting at 1 399€/seat

Purchase EZprofile®
